CQB40-25-200FL Fluoroplastic Alloy Magnetic Pump

Cancelled the shaft seal and used magnetic coupling to indirectly drive,completely eliminating the trouble of dripping and never polluting thesite. Due to the use of "fluoroplastic alloy" for the overcurrent part of thepump. It can continuously transport corrosive media such as acids, alkalis,and strong oxidants of any concentration without damage.

The driving device adopts an active magnetic coupling directly installedon the motor shaft, and the pump chamber is completely closed.Through magnetic coupling, the impeller with magnetic steel on thepump shaft is indirectly driven to rotate, which is compact, safe andenergy-saving.

Although the part in contact with the liquid is fluoroplastic, the pumpbody substrate is made of metal material, so the pump body canwithstand the weight and mechanical impact of some pipelines, and issturdy and durable.

Q1：Why can the CQB40-25-200FL magnetic pump achieve zero leakage when transporting highly corrosive media?

A: The pump adopts a magnetic coupling shaft seal free transmission structure, eliminating traditional mechanical shaft seals and relying on magnetic force to transmit torque, with the medium completely enclosed inside the pump chamber; The overcurrent component is lined with fluoroplastic, which structurally prevents leakage and is suitable for transporting toxic and volatile chemical media.

Q2: What situations can cause damage to the pump body during the use of this magnetic pump?

A: It is strictly prohibited to run idle, as idle running may cause high temperature wear and tear on the internal isolation sleeve; The medium must not contain large particles of hard impurities; The inlet pipeline must not leak air, and the cavitation allowance needs to meet the requirement of 3.5m working condition, otherwise it will reduce the service life of the pump.
